New
Case Construction 580 Super N Construction King Backhoe Loader
New
Case Construction 580 Super N Construction King Backhoe Loader
Model: 580SN
- 97 engine horsepower
- 14' 4" dig depth
- Up to 25-mph
Product Description
580 SUPER N CONSTRUCTION KING BACKHOE LOADER
"Super” is a title that has to be earned. Expanding on the rock-solid legacy of previous generations, the Tier 4 Final Super N is quicker, more powerful, more efficient and more productive than ever before. A re-engineered PowerDrive transmission option tackles hills and heavy loads with ease and the PowerBoost backhoe button releases ferocious digging force with no RPM loss. Benefit from the precision of ProControl, the fuel savings of ECO Mode and the business smarts of SiteWatch Telematics – all standard.
SWIFT, SMOOTH, AND PRECISE SWING
SITEWATCH TELEMATICS
Specs
| Additional Specs | |
|---|---|
| Cab Enclosure | Optional |
| Operator Station | ROPS |
| Engine | |
|---|---|
| Displacement | 207 cu in |
| Emissions Tier (EPA) | Tier 4 |
| Engine Model | FPT F5BFL413B |
| Fuel Type | Diesel |
| Gross HP | 97 hp |
| No. Of Cylinders | 4 |
| Performance | |
|---|---|
| Backhoe Dig Depth | 14' 6" |
| Backhoe lift Capacity | 3039-7424 lb |
| Breakout Force | 10947 lb |
| Travel Speed | 25 mph |
| Dump Angle @ Max Height | 47 degrees |
| Lift Capacity to Full Height | 7044 lb |
| Driveline | 4WD |
| Dimensions & Weight | |
|---|---|
| Dump Reach at Max Height | 31.5 in |
| Height to Bucket Hinge Pin | 11' 3" |
| Height with Operator Cab | 8' 11" |
| Length | 23' 5" |
| Operating Height | 13' 9" |
| Operating Weight | 17810-19750 lb |
| Wheel base | 84 in |
| Width | 86 in |
| Capacities | |
|---|---|
| Hydraulic Tank | 31.25 gal |
| Fuel Tank | 35 gal |
| Transmission | |
|---|---|
| Transmission | Power Shuttle |
| Transmission Range | 4F/4R |
| Make/Model | |
|---|---|
| Model | 580SN |
| Type | Backhoe |
| Product Dimensions & Weight | |
|---|---|
| Length | 281.00 in |
| Width | 86.00 in |
| Height | 130.00 in |
| Weight | 19067.00 lbs |
