Bobcat E10e Electric Compact Excavator

Bobcat E10e.jpg

Product Description

Bobcat E10e electric.jpg

MEET THE E10e EXCAVATOR

Quiet and emission-free, the zero tail-swing E10e compact excavator can work when and where other excavators can’t, offering more solutions for today’s diverse jobsites. The E10e is powered by two lithium-ion batteries that provide a total capacity of 11.5kWh. The batteries deliver high-energy density, long service life and require no routine maintenance. The result is strong breakout forces, smooth operator control functions and loads of workgroup power.

HIGHLY MANEUVERABLE

Bobcat E10e bucket.jpg
These zero tail-swing excavators can access hard-to-reach jobsites and tackle tough jobs in confined areas - where larger excavators can’t go. Producing no emissions, the E10e can take on hefty jobs - both outdoors and indoors. Because it generates little noise, the E10e can be operated at all hours of the day, even in dense urban centers and residential areas where noise can limit work hours. Hydraulically retract the undercarriage to just 28 in. to access these smaller areas then return to its 43 in. stance for a wider footprint.

FEWER COMPONENTS, FEWER REPAIRS

Bobcat E10e excavator.jpg
With fewer components and fluids, regular maintenance and repair costs are significantly reduced as well as work time lost to maintenance and repairs. All the regular maintenance that’s required to keep diesel engines in top running order is eliminated. The lithium-ion batteries that power the E10e, E19e and E32e require no routine maintenance and are protected against overcharging.

STANDOUT FEATURES

  • Control pattern selector.
  • Two-speed travel.
  • Auxiliary hydraulics with two-way flow.
  • Leading attachment versatility.
  • In-track swing frame.
  • An on-board charger, supports overnight charging of about 12 hours.
  • An optional, off-board, fast-charge system is also available for full battery recharge in just two hours.
Bobcat E10e dig.jpg

Specs

Additional Specs
Tail Swing Type
Zero
Operator Station
ROPS
Engine
Fuel Type
Electric
Performance
Arm Digging Force
1248 lbf
Battery Type
Lithium Ion
Bucket Digging Force
1865 lbf
Travel Speed
High: 1.8 mph, Low: 1.1 mph
System Voltage
51.8 v
Gross Battery Capacity
11.52 kW·h
Estimated Run Time
4 h
On-Board Charge Time-120V
10-12 h
On-Board Charge Time-240V
10-12 h
Off-Board Charge Time
2 h
Driveline
Track
Dimensions & Weight
Height
87 in
Length
110 in
Operating Weight
2648 lb
Size Class
1-4 Ton
Weight Class
1 t
Width
27.9 in
Hydraulic System
Auxiliary Std Flow
5.3 gal/min
Make/Model
Model
E10e
Type
Compact Excavator
Size Class
1-4 Ton
Product Dimensions & Weight
Length
110.00 in
Width
27.90 in
Height
87.00 in
Weight
2648.00 lbs
