Bobcat E19e Electric Compact Excavator

Bobcat E19e.jpg

Product Description

Bobcat E19e bucket.jpg

MEET THE E19e EXCAVATOR

With a small footprint, zero emissions and an in-track swing frame, the E19e can work on small outdoor jobsites as well as indoors, where the alternative is manual labor. The E19e is powered by three lithium-ion batteries that provide a total capacity of 17.28 kWh. The batteries deliver high-energy density, long service life and require no routine maintenance. The standard long-arm gives operators added reach and dig depth, while the increased cylinder size offers excellent breakout forces and lifting ability.

HYDRALICALLY RETRACTABLE UNDERCARRIAGE

Bobcat E19e excavator (1).png
Hydraulically retract the undercarriage to just 39-inches (38.6 spec) wide for access to small job sites - both indoors and out. Then return the undercarriage to its 54-inch stance (53.5 spec) for a wider footprint and leading performance. The dozer blade also can be retracted at each side for greater access to jobsites.

SUPERIOR PERFORMANCE

Bobcat E19e lift.png
The standard long-arm gives operators added reach and dig depth, while the increased cylinder size offers excellent breakout forces and lifting ability. The integrated rear counterweight lowers the center of gravity, further enhancing the stability of the undercarriage design. Operators can dig and slew with more confidence, improving digging performance.

STANDOUT FEATURES

  • Total battery capacity of 17.3 kWh.
  • Selectable control pattern
  • Conventional tail swing
  • Two-speed travel with auto shift.
  • Auxiliary hydraulics with two-way flow.
  • An optional off-board, fast-charge system is also available for full battery recharge in two hours.
  • An on-board charger, capable of receiving common electrical connections of 120 volts, supports overnight charging of about 12 hours.
Bobcat E19e dig.png

Specs

View Full Specs Here

Additional Specs
Tail Swing Type
Conventional
Operator Station
ROPS
Engine
Fuel Type
Electric
Performance
Arm Digging Force
2086 lbf
Battery Type
Lithium Ion
Bucket Digging Force
4684 lbf
Travel Speed
High: 2.3 mph, Low: 1.1 mph
System Voltage
51.8 v
Gross Battery Capacity
17.28 kW·h
Estimated Run Time
4 h
On-Board Charge Time-120V
10-12 h
On-Board Charge Time-240V
10-12 h
Off-Board Charge Time
2 h
Driveline
Track
Dimensions & Weight
Height
90.5 in
Length
150.1 in
Operating Weight
4212 lb
Size Class
1-4 Ton
Weight Class
2 t
Width
38.6 in
Hydraulic System
Auxiliary Std Flow
26.4 gal/min
Make/Model
Model
E19e
Type
Compact Excavator
Size Class
1-4 Ton
Product Dimensions & Weight
Length
150.10 in
Width
38.60 in
Height
90.50 in
Weight
4212.00 lbs
