Bobcat E35 (33hp) R-Series Compact Excavator

Bobcat E35 R Series

Product Description

Bobcat E35 grapple.jpg

MEET THE E35 (33HP) EXCAVATOR

The E35 is an industry exclusive high 33 horsepower, 3 ton excavator with a Bobcat engine. The Bosch fuel system increases fuel efficiency, produces better elemental starting ability, and a longer fuel filter life. This compact excavator is designed to excel by providing the performance, durability, quality, and versatility necessary to push operator productivity and profitability to the next level.

PERFORMANCE BOOST

Bobcat E35 33 hp.jpg
Option up for more versatility with performance-boosting features including a clamp-ready extendable arm, a long arm and an angle blade. Reach up to 30 in more than the standard arm with the extendable arm option with less repositioning. Dump spoil further away from the excavator and reach further back into the trench for cleanout purposes. Loading trucks is easier, too.

OPERATOR FRIENDLY CONTROLS

Bobcat E35 joysticks.webp
Simple, ergonomic controls keep you productive all day long. Control your attachments and travel with precision, flexibility and low fatigue. Feel the quality at your fingertips, as the newly designed  joysticks fit better in your hands.

BIG ON HYDRAULICS

An excavators hydraulic system contributes to performance more than any other feature. Whether your digging, backfilling, or traveling across a jobsite this 3 ton model features advanced hydraulics to deliver the most power when you need it. High-efficiency, torque-limiting piston pumps in the hydraulic system match force to demand, continuously responding to loads and delivering more usable power.

Bobcat E35 excavator.jpg

Specs

Additional Specs
Air Conditioning
Optional
Angle Blade
N/A
Cab Enclosure
Optional
Tail Swing Type
Conventional
Engine
Emissions Tier (EPA)
Tier 4
Fuel Type
Diesel
Gross HP
33 hp
Turbocharged Engine
No
Performance
Arm Digging Force
4690 lbf
Boom Swing Angle Left/Right
Boom Swing Left: 75 degrees, Boom Swing Right: 55 degree
Bucket Digging Force
7284 lbf
Lift Capacity
2975 lb
Travel Speed
2.9 mph
Max Dig Depth
121.2 in
Max Dump Height
137.2 in
Driveline
Track
Dimensions & Weight
Height with Operator Cab
96.2 in
Operating Weight
7403 lb
Reach @ Maximum Height
194.5 in
Size Class
1-4 Ton
Weight Class
3.4 t
Capacities
Fuel Tank
13.7 gal
Hydraulic System
Auxiliary Std Flow
16.9 gal/min
Auxiliary Pressure
2987 psi
Make/Model
Model
E35 (33hp)
Type
Compact Excavator
Size Class
1-4 Ton
