New
Case Construction CX60C Mini Excavator
New
Case Construction CX60C Mini Excavator
Model: CX60C
- 11' 9" dig depth
- 64.7 engine horsepower
- 12,940 lb. operating weight
Product Description
MEET THE CX60C EXCAVATOR
The CASE CX60C proves that giants come in all sizes. After all, this big mini excavator weighs just six metric tons, but it kicks out industry-leading horsepower along with nearly 9,200 lbs. of breakout force. Mated with the quick, responsive hydraulics, short-radius tailswing and adjustable boom, and you’ve got a machine that can crush big job after big job, even with little room to maneuver.
AUTO SHIFT TRAVEL
GROUNDLINE ACCESS
Specs
| Additional Specs | |
|---|---|
| Cab Enclosure | Standard |
| Tail Swing | 3' 7" |
| Tail Swing Type | Short radius |
| Operator Station | ROPS, Enclosed Cab |
| Engine | |
|---|---|
| Displacement | 203 cu in |
| Emissions Tier (EPA) | Tier 4 |
| Engine Model | Yanmar 4TNV98C |
| Fuel Type | Diesel |
| Gross HP | 64.7 hp |
| No. Of Cylinders | 4 |
| Performance | |
|---|---|
| Arm Digging Force | 5035-5950 lb |
| Boom Swing Angle Left/Right | 70 degrees left/50 degrees right |
| Bucket Digging Force | 9190 lb |
| Ground Pressure | 5.12 psi |
| Lift Capacity | See full spec sheet |
| Travel Speed | 2.5 mph |
| Max Dig Depth | 11' 9" |
| Max Dump Height | 12' 11" |
| Max Reach | 18' 8" |
| Driveline | Track |
| Dimensions & Weight | |
|---|---|
| Ground Clearance | 15 in |
| Height | 100 in |
| Length | 100 in |
| Operating Weight | 12940-13760 lb |
| Size Class | 4-8 Ton |
| Weight Class | 7 t |
| Width | 76 in |
| Capacities | |
|---|---|
| Hydraulic Tank | 29.1 gal |
| Fuel Tank | 21.7 gal |
| Hydraulic System | |
|---|---|
| Hydraulic System | Gear |
| Transmission | |
|---|---|
| Transmission | Hydrostatic (HST) |
| Make/Model | |
|---|---|
| Model | CX60C |
| Type | Compact Excavator |
| Size Class | 4-8 Ton |
| Product Dimensions & Weight | |
|---|---|
| Length | 219.00 in |
| Width | 78.00 in |
| Height | 100.00 in |
| Weight | 13760.00 lbs |
