Kubota KX040-5 Compact Excavators

Kubota KX040-5 studio

Product Description

Kubota KX040-5 Excavator

MEET THE KX040-5 COMPACT EXCAVATOR

The Kubota KX040-5 compact excavator is built for performance and precision, offering an innovative design with a powerful engine and enhanced hydraulics for maximum productivity. Its spacious and comfortable operator cabin, combined with advanced control systems, ensures you can work longer and smarter. Designed to tackle tough tasks with ease, the KX040-5 is your go-to solution for superior digging power and reliability on any job site.

ANGLE BLADE OPTION

KX040-5 Blade
Save time and work more efficiently. With a simple movement of the blade lever, the hydraulic angle blade can be angled to the right or left to push soil to the side as the machine moves forward, eliminating the need for repetitive repositioning at right angles when backfilling trenches.

HYDRAULIC 6-IN-1 BLADE OPTION

KX040-5 blade 2
The 6-in-1 blade is a true productivity enhancer. It can be angled right and left, and tilted as well. This blade enables six different positions: neutral, float-up, left-end-up, right-end-up, left-end-forward, and right-end-forward. This feature makes leveling and backfilling work incredibly easy, even on inclines and uneven terrain, making you more productive and more efficient.

KUBOTANOW TELEMATICS

The Kubota telematics solution connects your Kubota equipment to your tools. Get critical information like accumulated hours, fuel level, location, temperatures and more. KubotaNOW gives you the right information when and where you need it.

KX040-5 telematics

Specs

Additional Specs
Operator Station
ROPS | Cab
Engine
Displacement
111.4 cu in
Engine Model
Kubota D1803-CR-TE5-BH5 | Kubota D1803-CR-TE5-BH6
Gross HP
40.3 hp
Performance
Arm Digging Force
4114 lb
Bucket Digging Force
9397 lb
Ground Pressure
4.5-5.1 psi
Travel Speed
3.1 mph
Dimensions & Weight
Ground Clearance
1 ft
Size Class
4-8 Ton
Capacities
Fuel Tank
17.4 gal
Hydraulic System
Auxiliary Std Flow
9.8-17.2 gpm
Make/Model
Model
KX040-5
Type
Compact Excavator
Size Class
4-8 Ton
Product Dimensions & Weight
Length
200.00 in
Width
71.00 in
Height
98.00 in
Weight
9645.00 lbs
