New
Kubota DM5040 Disc Mower
New
Kubota DM5040 Disc Mower
Model: DM5040
- 13' 1" Cutting Width
- 12' 5" Transportation Width
- 10 Disc's and 30 Knives
Product Description
DM5040 DISC MOWER
The Kubota DM5040 doesn’t just bring you trouble free mowing and outstanding cut quality, the disc mower takes it even further with its secure and convenient transportation system. The DM5040 can quickly go from a 13’1” working width to 12’6” for transporting by folding in the side guards. Designed for maximum durability, this mower has active suspension to make mowing through rough conditions possible. Improved grass flow and easier operation on crops provides you with the results you’ve been searching for.
DRAWBAR SWIVEL HITCH GEARBOX
The drawbar swivel hitch gearbox is fixed to the mainframe in order to minimize movement during operation, yet it provides unlimited rotational movement between the machine and the tractor making it easier to perform sharp turns.
Specs
| Additional Specs | |
|---|---|
| Break Away | N/A |
| Hitch (CAT) | Cat II |
| Minimum PTO HP Required | 85 hp |
| Performance | |
|---|---|
| Cutting Width ft. | 13' 1" |
| Driveline | Pull-Type |
| PTO RPM | 540 rpm |
| Dimensions & Weight | |
|---|---|
| Pin Hitch | Standard |
| Transport Width ft. | 12' 5" |
| Disc Mower Conditioner Specs | |
|---|---|
| Cutterbar Operating Angle | ±17 |
| Number Of Discs and Knives | 10/30 |
| Remotes | 2 |
| Stubble Height in. | 1.79"-3.94" |
| Make/Model | |
|---|---|
| Model | DM5040 |
| Type | Disc Mower |
| Product Dimensions & Weight | |
|---|---|
| Length | 0.00 in |
| Width | 157.00 in |
| Height | 0.00 in |
| Weight | 2778.00 lbs |
