Kubota DMC8536R Disc Mower Conditioner
New
Kubota DMC8536R Disc Mower Conditioner
Model: DMC8536R
- 11' 10" Working Width
- 11' 2" Transportation Width
- Chevron Roller Conditioner Type
Product Description
DMC8536R DISC MOWER CONDITIONER
Whether you need your mower on the left or right side, the Kubota DMC8536R center pivot disc mower has got you covered. An impressive working width of 11’ 10” ensures you’re covering plenty of ground, and the rotating, three bladed discs with independent suspension keeps that precision going, even on variable terrain. When the job is all said and done, a 11’ 2” transport width gets you easily back to the homestead and doesn’t impose on your windrows. Versatility like you’ve never experienced before, the DMC8536R is here to impress.
ROLLER CONDITIONING
The 8.8-inch wide rollers crafted from tough polyurethane and a steel core, offers a gentle but effective way to handle delicate crops such as alfalfa and clover. The spring-controlled pressure between the rollers provides consistent conditioning while the spring tension system protects the conditioner by allowing the rollers to open up to 2.4 inches, letting the object pass without harm.
Specs
| Additional Specs | |
|---|---|
| Drawbar | Center |
| Hitch (CAT) | Cat II |
| Minimum PTO HP Required | 70 hp |
| Performance | |
|---|---|
| Cond. Roto Speed | 900 |
| Driveline | Pull-Type |
| PTO RPM | 540 rpm |
| Dimensions & Weight | |
|---|---|
| Tire Size | 380/55-17 |
| Working Width ft. | 11' 10" |
| Disc Mower Conditioner Specs | |
|---|---|
| Cutterbar Operating Angle | ±17 degree |
| Number Of Discs and Knives | 10 discs |
| Remotes | 2 |
| Stubble Height in. | 1.18-1.57 in |
| Make/Model | |
|---|---|
| Model | DMC8536R |
| Type | Disc Mower Conditioner |
| Conditioning Systems | |
|---|---|
| Roll Type | Roller conditioner |
| Product Dimensions & Weight | |
|---|---|
| Length | 0.00 in |
| Width | 142.00 in |
| Height | 0.00 in |
| Weight | 5348.00 lbs |
