New Holland Durabine 416 Plus Header
New
New Holland Durabine 416 Plus Header
Model: 416 Plus
- 10 discs
- 16' 3" cutting width
- MowMax II Plus Cutterbar
Product Description
NEW HOLLAND DURABINE 416 PLUS
With a cut width of 16’ 3” (4.95 m), the Durabine 416 PLUS is built to capitalize on the fast speeds of Speedrower 220 PLUS and 260 PLUS windrowers. The modular MowMax II PLUS cutterbar, QuickMax knife-change system, and low-profile ShockPRO hubs come standard. A knife tip speed of 195 mph (314 kph) at 2600 rpm is achieved, which is 14 mph (22 kph) faster than the prior series. A heavy-duty full-length constant flow auger quickly moves crop away from the cutterbar for increased capacity, uniform conditioning, and an evenly-distributed windrow. To optimize crop flow, conditioning, and improve windrow center fill, Durabine 416 PLUS disc rotation delivers the crop in four streams into the Constant Flow Auger. Three conditioning systems are optional: chevron-pattern steel, rubber conditioning rolls, or B&D Roller’s—provides longer wear and softer hay.
Specs
| Dimensions & Weight | |
|---|---|
| Overall Width | 16' 7" |
| Pickup | |
|---|---|
| Flotation | Hydraulic adjustment from cab |
| New Holland Headers | |
|---|---|
| Auger Type | Floating |
| Make/Model | |
|---|---|
| Model | Durabine 416 Plus |
| Type | Windrower Headers |
| Conditioning Systems | |
|---|---|
| Roll Type | Chevron pattern rubber or steel or B&D's "The Crusher" rubber rolls |
| Roll Speed (rpm) | 938 rom |
| Roll Pressure | Hand crank |
| Roll Gap | Adjustable stop-bolt |
| Windrow/Swath Width in. (mm) | 38 to 96 (965 to 2438) |
| Product Dimensions & Weight | |
|---|---|
| Length | 0.00 in |
| Width | 199.00 in |
| Height | 0.00 in |
| Weight | 5114.00 lbs |
