New Holland Speedrower 160 Plus Self-Propelled Windrower
New
New Holland Speedrower 160 Plus Self-Propelled Windrower
Model: 160 Plus
- FPT 4-cylinder engine
- 150 rated horsepower
- 20-22 mph top speed
Product Description
MEET THE SPEEDROWER 160 PLUS WINDROWER
The Speedrower 160 Plus is powered by a 150-161 HP FPT 4-cylinder engine and features a three-way adjustable telescopic steering wheel and a right-hand seat-mounted console that moves with the seat. Its 73 square feet (6.8 square meters) of curved, tinted cab glass provides excellent visibility, complemented by a quiet environment, high-capacity air conditioning, and a choice of cab packages with either cloth or premium leather seats with heating and cooling.
EFFORTLESS PRODUCTIVITY
INTELLIVIEW IV DISPLAY
HEADLAND MANAGEMENT AUTOMATION
Repetitive activities can lead to fatigue and reduced productivity, especially during long mowing days. Headland Management Automation simplifies headland turns and improves pass-to-pass accuracy by controlling ground speed, header lift, and merger lift with a single button, helping to reduce fatigue and maintain productivity.
Specs
| Additional Specs | |
|---|---|
| IntelliView IV Touch Screen | Standard |
| Engine | |
|---|---|
| Aspiriation | Turbocharged with air-to-air intercooler |
| Displacement | 247 cu in (4.5 L) |
| Engine Model | FPT 4-cylinder, Tier 4B |
| Fuel Injection Pump | Electronically controlled high-pressure common rail |
| Constant Clean, Rotating Wand Cooling System Pre-Cleaner | Standard |
| Dimensions & Weight | |
|---|---|
| Wheel base | 154.1 in |
| Length With Header (in. (mm)) | 290.5 (7366) with HS Series |
| Capacities | |
|---|---|
| DEF | 19 gal (71.9 L) |
| Fuel Tank | 120 gal (454 L) |
| Transmission | |
|---|---|
| Transmission | Hydrostatic (HST) |
| Operating Modes | In-field/Transport |
| Final Drive | Double reduction planetary |
| Hydrostatic Steering | Electronically Controlled - Customizable Resistance |
| CommandGrip™ controlled customizable speed controls | Standard |
| In-field Speed Range (mph (kph)) | 0-20 (0-32) |
| Windrower Specs | |
|---|---|
| Factory IntelliSteer™ Auto Guidance ready | Standard |
| Headland Management Automation with speed control | Standard |
| IntelliSteer™ Auto Guidance - high cross track error engagement | Standard |
| IntelliSteer™ Auto Guidance - line acquisition speed range (mph (kph)) | 0-10 (0-16) |
| IntelliSteer™ Auto Guidance - maximum line acquisition angle (degrees) | Up to 90 degrees |
| Terraglide™ Rear Axle Suspension Articulation (degrees) | 12 degrees |
| Make/Model | |
|---|---|
| Model | Speedrower 160 Plus |
| Type | Windrower |
| Header Drive | |
|---|---|
| Header Drive Pump Type | Fixed Displacement |
| Max. header drive pump output at 2,200 engine RPM (gpm (Lpm)) | 31.6 (120) |
| Header Power Reverser | Standard |
| Header Flotation | Single hydraulic (in-cab adjustable) |
| Hydraulic Header Tilt | Standard |
| Single Lever Header Transport Lock System | Standard |
| Product Dimensions & Weight | |
|---|---|
| Length | 290.50 in |
| Width | 148.50 in |
| Height | 134.30 in |
| Weight | 12225.00 lbs |
