New Holland Stackcruiser 105 Bale Wagon
New
New Holland Stackcruiser 105 Bale Wagon
Model: Stackcruiser 105
- New Holland 6.7L engine
- Large square bales
- Up to 15 bales per load
Product Description
NEW HOLLAND STACKCRUISER 105
The Stackcruiser 105 is the best solution for dedicated handling of large square bales since it omits components needed to handle small square bales, saving you money. The functionality of a rocker switch gives you control of the two-speed rear axle with automatic locking rear differential to keep you moving in slippery or uneven conditions. Five-speed automatic transmission with lock-up torque converter provides excellent speed matching ability. First gear, slower ground speed for high-density crops and overdrive in fifth gear allowing fast 50-mph road transport.
Specs
| Engine | |
|---|---|
| Aspiriation | Turbocharged & after cooled |
| Dimensions & Weight | |
|---|---|
| Gross Vehicle Weight | 14969 lbs |
| Length | 31.25 ft |
| Capacities | |
|---|---|
| DEF | 12.4 gal (47 L) |
| Fuel Tank | 69 gal (261 L) |
| Hydraulic System | |
|---|---|
| Hydraulic System | Dual: open center and
closed center |
| Transmission | |
|---|---|
| Transmission | Automatic |
| Transmission Range | 5-Speed |
| Bale Wagon Specs | |
|---|---|
| Bale Capacity | 3 ft x 3 ft x 8 ft: 15, 3 ft x 4 ft x 8 ft: 10 |
| Bale Sizes capable - Height x Width x Length (in. (cm)) | 3 ft x 3 ft x 8 ft (91 cm x 91 cm x 244 cm), 3 ft x 4 ft x 8 ft (91 cm x 122 cm x 244 cm) |
| Bale Weight | 7080 lbs max. load |
| Loader Raised, Stabilizers Off (in. (cm)) | 116 (295) with BB loader |
| Maximum Power at Rated Speed (hp (kW)) | 190 (142) |
| Number of cylinders / displacement (cu. in. (L)) | 6 / 408 (6.7) |
| Rear Axle | 10 (25) @ diff. housing, 6 (15) at leaf spring U-bolts |
| Make/Model | |
|---|---|
| Model | Stackcruiser 105 |
| Type | Bale Wagon |
| Product Dimensions & Weight | |
|---|---|
| Length | 375.00 in |
| Width | 199.00 in |
| Height | 0.00 in |
| Weight | 14969.00 lbs |
