Bobcat L95 Compact Wheel Loader

Bobcat L95

Product Description

Bobcat L95 wheel loader.jpg

MEET THE L95 WHEEL LOADER

The L95 compact wheel loader's compact size, tight turning radius and Power Bob-Tach attachment mounting system ensure maximum versatility for numerous jobs. The advanced Tier 4, turbocharged engine delivers powerful, high-torque performance, excellent efficiency and achieves emissions compliance without the use of a diesel particulate filter (DPF) or selective catalyst reduction (SCR). With low noise levels in the cab, an oscillating frame, and automatic ride control, the L95 provides an exceptional ride quality that enhances the operator experience providing comfort from start to finish.

FOUR SPEED VERSATILITY

Bobcat L95 travel modes.jpg
You can adapt the performance of your compact wheel loader to whatever the job requires. A convenient switch on the joystick allows the operator to easily change speed modes on or between jobsites. The L95 also offers both low range and high range within each speed mode. This gives you four travel speeds to match the demands of every task.

HIGH FLOW HYDRAULICS

Bobcat L95 hydraulics.jpg
The L95 comes standard with high-flow hydraulics that provide up to 27 gpm. This allows operators to maintain peak efficiency while operating approved hydraulic attachments. Dual-direction detent allows hydraulic flow to be engaged continuously, in either direction, without holding a switch.

Specs

Additional Specs
Air Ride Susp Seat
Optional
Cab Enclosure
Standard
Keyed Ignition
Standard
Speedometer
Standard
Operator Station
ROPS, Enclosed Cab
Engine
Emissions Tier (EPA)
Tier 4
Engine Cooling
Liquid
Fuel Type
Diesel
Gross HP
74 hp
Turbocharged Engine
N/A
Performance
Articulation Angle
40 degree
Bucket Capacities
28.6 ft³/0.81 m³
Rated Operating Capacity (ISO)
3981 lbs
Tipping Capacity
7962 lbs
Dump Angle @ Max Height
45 degree
Driveline
4WD
Dimensions & Weight
Ground Clearance
13.3 in
Height with Operator Cab
99.3 in
Length with Standard Bucket
219.3 in
Oscillation Angle
8 degree
Operating Weight
11993 lbs
Tire Size
405/70 R20
Turning Radius Outside
150.7 in
Wheel base
82.7 in
Width (with bucket)
74.8 in
Width
70.9 in
Capacities
Fuel Tank
20.8 gal
Hydraulic System
Auxiliary High Flow
27.3 gpm
Pump Capacity
19.9 gpm
Transmission
Transmission
Hydrostatic (HST)
Transmission Range
2-Speed
Make/Model
Model
L95
Type
Wheel Loader
Product Dimensions & Weight
Length
219.30 in
Width
74.80 in
Height
99.30 in
Weight
11993.00 lbs
