Bobcat S510 M3-Series Skid-Steer Loader

Bobcat S510

Product Description

Bobcat S510 skid steer.jpg

MEET THE S510 SKID STEER

Whether you're on a construction site, a landscaping project or tackling farm and ranch work, take your productivity to the next level with the 55-hp Bobcat S510 skid-steer loader. Offering an industry-leading breakout force, quicker turns and faster cycle times. On-board diagnostics troubleshoot problems in the field and, in many cases, prevent them from occurring in the first place. Leading all-around visibility is central to the design of the S510's optional cab. The cab, designed with operator visibility at the forefront, provides a big advantage when loading a truck or using attachments.

HIGH TORQUE

Bobcat S510 bucket.jpg
Higher combustion pressures generate more torque. Bobcat engines have a robust combustion chamber that handles more pressure and produces high torque levels at low rpm operation. You’ll notice better performance for pushing, digging, lifting and operating attachments with less chance of stalling.

RADIUS LIFT PATH

Bobcat S510 With Bucket
A radius lift path provides maximum reach at truck bed height. Arm movement forms an arc. More than 80% of that arc delivers better reach at truck bed height. A radius lift path excels in jobs at mid-range heights, like dumping, backfilling or unloading flatbed trucks.

OPERATOR COMFORT

To accomplish more on today’s challenging jobs, comfort is as important as performance and productivity. When you can work comfortably, you’re more focused on the job and able to do more. Bobcat M3-Series loaders deliver a long list of standard comfort features to make long days on the job easier – including cab pressurization, ample headroom and legroom, and an adjustable suspension seat.

Bobcat S510 forks.jpg



Specs

Additional Specs
Cab Enclosure
Optional
Operator Station
ROPS
Engine
Emissions Tier (EPA)
Tier 4
Engine Cooling
Liquid
Engine Shutdown
Standard
Fuel Type
Diesel
Gross HP
55 hp
Turbocharged Engine
Yes
Performance
Rated Operating Capacity (ISO)
1876 lb
Travel Speed
7.6 mph
Tipping Load
3560 lb
Driveline
4WD
Dimensions & Weight
Height to Bucket Hinge Pin
114.5 in
Height with Operator Cab
77.8 in
Length with Standard Bucket
133 in
Length without Attachment
104.6 in
Operating Weight
6208 lb
Reach @ Maximum Height
17 in
Turning Radius
80 in
Wheel base
42.6 in
Width (with bucket)
68 in
Capacities
Fuel Tank
24.8 gal
Hydraulic System
High Flow Option
Optional
Auxiliary Hydraulics
Optional
Auxiliary Std Flow
17.1 gal/min
System Relief @ Quick Couplers
3550 psi
Transmission
Transmission
Hydrostatic (HST)
Two Speed Travel
Standard
Make/Model
Model
S510
Type
Skid-Steer Loader
Product Dimensions & Weight
Length
133.00 in
Width
68.00 in
Height
77.80 in
Weight
1876.00 lbs
