Bobcat T650 M3-Series Compact Track Loader

Selected Bobcat T650
Bobcat T650

Product Description

Bobcat T650 track loader.jpg

MEET THE T650 TRACK LOADER

The Bobcat M3-Series T650 compact track loader, with its vertical lift path, offers proven performance and customizable features for a productive and reliable machine. It boasts efficient hydraulics, powerful breakout forces, and excellent lift capacity for faster material handling. A wide range of attachments provides exceptional versatility and value, enabling owners to accomplish more with one durable machine.

DURABLE UNDERCARRIAGE

Bobcat T650 undercarriage.jpg
The undercarriage on M3-Series compact track loaders delivers excellent ride quality, tough construction, optimal productivity and impressive ground clearance. The forged steel idlers and steel imbed tracks are built for the longest-possible service life with minimal maintenance. Solid-mounted drive motors and hydraulic hoses are better protected from debris, snags, vibrations, rubbing, mud and sticks. And rubber track options provide a smooth ride without impacting your capabilities.

VERTICAL LIFT PATH

Bobcat vertical lift.png
A vertical lift path provides higher lift capacity and more reach at full lift height than a radius lift path, keeping the load closer to the machine while raising the loader arms. The lift arms feature cast-steel construction in specific areas for increased material strength and rigidity. Use of cast steel allows for greater strength with a slimmer profile arm, enhancing visibility to the bucket corners.

STANDARD FEATURES

  • Powerful 74-hp engine
  • Fingertip controls for easy attachment operations
  • Dial throttle control for quick engine speed adjustments
  • 12-volt power accessory to charge mobile devices
  • Patented, dual-path cooling system
  • Bob-Tach mounting system for quick attachment changes
  • Battery run-down protection
Bobcat T650 bucket.jpg



Specs

Additional Specs
Air Conditioning
Optional
Cab Enclosure
Optional
Cab Heater
Optional
Operator Station
ROPS
Engine
Emissions Tier (EPA)
Tier 4
Engine Cooling
Liquid
Engine Shutdown
Standard
Fuel Type
Diesel
Gross HP
74 hp
Turbocharged Engine
Yes
Performance
Ground Pressure
5.7 psi
Rated Operating Capacity (ISO)
2570 lb
Travel Speed
6.2 mph
Operating Capacity (50% of Tip)
3670 lb
Tipping Load
7343 lb
Driveline
Track
Dimensions & Weight
Height to Bucket Hinge Pin
124 in
Height with Operator Cab
81.3 in
Length without Attachment
108.4 in
Length of Track on Ground
57.7 in
Operating Weight
9113 lb
Reach @ Maximum Height
36 in
Track Width
12.6 in
Width (with bucket)
74 in
Capacities
Fuel Tank
43.9 gal
Hydraulic System
High Flow Option
Optional
Auxiliary Hydraulics
Standard
Auxiliary Std Flow
23 gal/min
System Relief @ Quick Couplers
3500 psi
Transmission
Transmission
Hydrostatic (HST)
Travel Speed (2-speed option)
8.7 mph
Make/Model
Model
T650
Type
Track Loader
Product Dimensions & Weight
Length
136.80 in
Width
74.00 in
Height
81.30 in
Weight
2570.00 lbs
