New
Case Construction 1021G Full Size Wheel Loader
New
Case Construction 1021G Full Size Wheel Loader
Model: 1021G
- Up to 22-mph
- 218 engine horsepower
- 56,365 lb. operating weight
Product Description
MEET THE 1021G WHEEL LOADER
The CASE 1021G (318 horsepower (237 kW); 56,365 pounds) delivers speed and power for high-capacity production environments, and extremely powerful breakout forces and material handling capabilities for large-scale heavy construction — all while delivering excellent fuel efficiency without sacrificing any performance. With adjustable electro-hydraulic controls, a touchscreen display and collaborative fleet management technologies, the 1021G delivers a powerful combination of productivity, efficiency and uptime — all protected by CASE ProCare.
Specs
| Additional Specs | |
|---|---|
| Cab Enclosure | Standard |
| Keyed Ignition | Standard |
| Operator Station | ROPS, Enclosed Cab |
| Engine | |
|---|---|
| Bore X Stroke | 4.61 x 5.31 in |
| Displacement | 531 in³ |
| Emissions Tier (EPA) | Tier 4 |
| Engine Cooling | Liquid |
| Engine Model | FPT F2CFE614H |
| Fuel Type | Diesel |
| Gross HP | 318 hp |
| No. Of Cylinders | 6 |
| Turbocharged Engine | Yes |
| Performance | |
|---|---|
| Breakout Force | 45056 lb |
| Bucket Capacities | 4.56-5.50 yd³ (heaped) |
| Lift Capacity | 27705-31048 lb (full height) |
| Travel Speed | 4.3-22 mph |
| Tipping Load | 35717 lb (full turn tupping load ISO) |
| Dump Angle @ Max Height | 50-53 degrees |
| Driveline | 4WD |
| Dimensions & Weight | |
|---|---|
| Ground Clearance | 17.2 in |
| Height | 140.8 in |
| Height to Bucket Hinge Pin | 167.2 in |
| Height with Operator Cab | 140.8 in |
| Length | See full spec sheet |
| Operating Weight | 56365 lb |
| Reach @ Maximum Height | 49.8-55.6 in |
| Tire Size | 26.5-R25 L3 Radial |
| Turning Radius Outside | 250.6 in |
| Wheel base | 139.8 in |
| Width (with bucket) | 125.8-126.9 in |
| Width | 117.2 in |
| Capacities | |
|---|---|
| DEF | 24 gal |
| Hydraulic Tank | 66 gal |
| Fuel Tank | 125 gal |
| Hydraulic System | |
|---|---|
| Aux Hydraulics Pressure | 3495-3650 psi |
| Transmission | |
|---|---|
| Transmission | Powershift |
| Transmission Range | 4F/3R |
| Make/Model | |
|---|---|
| Model | 1021G |
| Type | Wheel Loader |
| Product Dimensions & Weight | |
|---|---|
| Length | 352.30 in |
| Width | 117.20 in |
| Height | 140.80 in |
| Weight | 58711.00 lbs |
