Case Construction 121F Compact Wheel Loader
New
Case Construction 121F Compact Wheel Loader
Model: 121F
- Up to 12.4-mph
- 64 engine horsepower
- 11,618 lb. operating weight
Product Description
MEET THE 121F WHEEL LOADER
The 121F is smaller in size but bigger in performance. A solid compact design offers greater weight distribution, enabling greater lifting capacity and maneuverability. The F Series cab provides operators greater visibility & comfort, improved attachment performance and versatility thanks to a standard skid steer coupler, and XT or Z-Bar linkage options. And the maintenance-free Tier 4 emission solution meets emissions regulations with no regeneration, no expensive DPF filters to replace, no extreme regeneration exhaust temperatures, and no after treatment fluids to add.
Specs
| Additional Specs | |
|---|---|
| Cab Enclosure | Standard |
| Keyed Ignition | Standard |
| Operator Station | ROPS, Enclosed Cab |
| Engine | |
|---|---|
| Bore X Stroke | 3.9 x 4.3 in |
| Displacement | 207 cu in |
| Emissions Tier (EPA) | Tier 4 |
| Engine Cooling | Liquid |
| Engine Model | FPT F5H FL463 C*F001 |
| Fuel Type | Diesel |
| Gross HP | 64 hp |
| No. Of Cylinders | 4 |
| Performance | |
|---|---|
| Breakout Force | 8971 lb |
| Bucket Capacities | 1.05 yd³ (heaped) |
| Lift Capacity | 5119-5265 lb (full height) |
| Rated Operating Capacity (ISO) | 3449-3586 lb |
| Travel Speed | 3.1-12.4 mph |
| Tipping Load | 6898 lb (full turn tipping load ISO) |
| Dump Angle @ Max Height | 44 degrees |
| Driveline | 4WD |
| Dimensions & Weight | |
|---|---|
| Ground Clearance | 12.6 in |
| Height | 96.7 in |
| Height to Bucket Hinge Pin | 123.5 in |
| Height with Operator Cab | 96.7 in |
| Length | 222.2 in |
| Length with Standard Bucket | 222.2 in |
| Operating Weight | 11023-11949 lb |
| Reach @ Maximum Height | 39.7 in |
| Rollback Angle | 38-57 degrees |
| Tire Size | 335/80 R18 Dunlop |
| Turning Radius Outside | 146.5 in |
| Wheel base | 81.7 in |
| Width (with bucket) | 80.7-82.7 in |
| Width | 68.5 in |
| Capacities | |
|---|---|
| Hydraulic Tank | 14 gal |
| Fuel Tank | 22.7 gal |
| Hydraulic System | |
|---|---|
| Aux Hydraulics Pressure | 3336 psi |
| Transmission | |
|---|---|
| Transmission | Hydrostatic (HST) |
| Make/Model | |
|---|---|
| Model | 121F |
| Type | Wheel Loader |
| Product Dimensions & Weight | |
|---|---|
| Length | 223.40 in |
| Width | 68.50 in |
| Height | 96.70 in |
| Weight | 11618.00 lbs |
