New
New Holland TH7.42 Plus Telehandler
New
New Holland TH7.42 Plus Telehandler
Model: TH7.42 Plus
- 22.9 ft. lift height
- 133 horsepower
- 17,637 lb. operating weight
Product Description
NEW HOLLAND TH7.42 PLUS
The TH7.42 PLUS telehandler, with its 133 horsepower engine and full-time 4WD, is built for versatility and performance on mixed farms. It features three steering modes, including four-wheel steering for a tight 12.8-foot turning radius, crab steer for diagonal movement around obstacles, and front-wheel steering for easy transport. Equipped with a smooth 4F/3R powershift transmission, the TH7.42 PLUS allows clutch-free gear changes, and its joystick-controlled boom and transmission functions ensure maximum productivity and comfort.
Specs
| Additional Specs | |
|---|---|
| Air Conditioning | Standard |
| Engine | |
|---|---|
| Aspiriation | Trubo intercooler |
| Displacement | 274 cu in |
| Emissions Tier (EPA) | Tier 4 |
| Engine Oil | 3.2 gal |
| Performance | |
|---|---|
| Lift Capacity | 9259 lbs |
| Lift Height | 276 in |
| Travel Speed | 21 mph |
| Rated Capacity @ Full Height | 5511 lbs |
| Rated Capacity @ Max Reach | 3306 lbs |
| Max Reach | 159 in |
| Dimensions & Weight | |
|---|---|
| Height | 96 in |
| Length | 261 in |
| Operating Weight | 17637 lbs |
| Wheel base | 118 in |
| Width | 92 in |
| Capacities | |
|---|---|
| Fuel Tank | 36.9 gal |
| Hydraulic Oil Tank gal. | 27.7 gal |
| Engine Oil | 3.2 gal |
| Hydraulic System | |
|---|---|
| Variable Pump (gpm (Lpm)) | 36.9 gpm |
| Transmission | |
|---|---|
| Transmission | Powershift |
| Make/Model | |
|---|---|
| Model | TH7.42 Plus |
| Type | Telehandler |
| Product Dimensions & Weight | |
|---|---|
| Length | 261.00 in |
| Width | 92.00 in |
| Height | 96.00 in |
| Weight | 17637.00 lbs |
