New Holland P2080 Air Disc Drill
New
New Holland P2080 Air Disc Drill
Model: P2080
- 30, 40, 50, or 60 ft. toolbar width options
- 7.5 and 10 in. available spacing options
- 5-8 mph operating speed
Product Description
P2080 AIR DISC DRILL
The P2080 disc drill model is specifically designed for P1000 Series air cart applications. It’s offered in 30, 40, 50 and 60 ft. (9.1, 12.2, 15.2 and 18.3 m) widths in 7.5 or 10 in. (19.1 or 25.4 cm) spacing for big acres and maximum productivity. The frame design offers exceptional weight distribution that is ideal for many different crops and soil types. In addition, the narrow V-shape envelope adds additional stability for safe and convenient transport to and from the field.
Specs
| Additional Specs | |
|---|---|
| Minimum PTO HP Required | 145-465 hp |
| Dimensions & Weight | |
|---|---|
| Length w/ Rear Hitch Pin | 36.4-38.6 ft |
| Transport Height | 13-14.75 ft |
| Transport Width ft. | 12-18.7 ft |
| Toolbar Width | 30 ft, 40 ft, 50 ft, 60 ft |
| Hydraulic System | |
|---|---|
| Hydraulic Requirements | 30 gpm -3 remotes |
| Seeding Specs | |
|---|---|
| Available Spacing | 7.5 in, 10 in |
| Discs (in. (cm)) | 18 in (45.7) at 7 degrees |
| Display System | Requires an ISO11783 compliant display such as Intelliview IV |
| No. Of Row Units | 36-96 |
| Wing Flex | 15 degrees up, 10 degrees down |
| Wing Sections | 30 & 40 ft options: 3, 50 & 60 ft options: 5 |
| Make/Model | |
|---|---|
| Model | P2080 |
| Type | Air Disc Drill |
| Product Dimensions & Weight | |
|---|---|
| Length | 463.20 in |
| Width | 124.40 in |
| Height | 177.00 in |
| Weight | 45500.00 lbs |
