New Holland T7.230 Tractor

N H T7.230

Product Description

New Holland T7.230 Tractor

MEET THE T7.230 CLASSIC TRACTOR

When you require more capacity for working larger hay fields, tending big livestock herds or managing row crops, but don’t need all the bells and whistles of PLM Intelligence the T7.230 long wheelbase is the perfect option. With a horsepower range of 180-225, the Power Command (full-powershift) transmission and 104-gallon fuel tank capacity, your T7 isn’t going to back down from a challenge.

POWER COMMAND TRANSMISSION

New Holland T7.230 variable ratio steer.png
The Power Command transmission lets you select the gear speed you want by simply pushing up or downshift buttons. Choose between a 25-mph 18x6 or 28x12 creep speed transmission or opt for an extra high ratio 19x6 or 29x12 directdrive alternative. This can deliver either 25 mph at reduced engine speed for economy or a high 31 mph transport speed.

HORIZON CAB

New Holland T7 classic armrest.png
The T7.230 is built to be tough and perform at the highest of levels. But is also designed to go easy on your wallet. These models come with the Horizon cab that features all-around visibility, exceptionally low noise levels, optional cab suspension, and advanced seating options to keep you comfortable all day long. With the Classic armrest, controls are simple to use and mechanical remote levers are easily accessible.

Specs

Engine
Aspiriation
Turbocharged/ air-to-air intercooled
Displacement
411 in³
Emissions Tier (EPA)
Tier 4B/Final Stage V
Engine Model
FPT NEF
Gross HP
180 hp
Max EPM HP
225 hp
No. Of Cylinders
6
No. of Cylinders/ Valve/ Displacement
6/4/411 in³
Performance
PTO HP
150 hp
Rear Linkage Cat.
Cat II/III
Front linkage lift capacity (24 in. (610 mm) in front of ball ends) (lbs. (kg))
8318 lbs
Dimensions & Weight
Operating Weight
18740 lbs
Rear Axle Length (in. (mm))
14 & 98 in
Wheel base
113.5-117.2 in
Capacities
DEF
13 gal
Fuel Tank
104 gal
Hydraulic System
System Type
Closed Center Load Sensing (CCLS)
Standard Pump Flow
Mechanical
Main Pump Flow Standard/ MegaFlow option ( Range & Power Command)
32/40 gpm
Main Pump Flow Standard/ MegaFlow option (Auto Command)
40/45 gpm
Transmission
PowerCommand ( full-powershift)
25-31 mph
Transmission
Powershift
Transmission Range
18x6
Make/Model
Model
T7.230
Type
Ag Tractor
Product Dimensions & Weight
Weight
18740.00 lbs
