New Holland Workmaster 40 Tractor

N H W M40

Product Description

NH WM

NEW HOLLAND WORKMASTER 40

With the highest horsepower of the compact Workmaster Series tractors, the Workmaster 40 offers just that 40 horsepower and up to 34 PTO horsepower with the 12 x 12 gear transmission. The 3-range hydrostatic transmission is also available with 32 PTO horsepower. This model features the turbocharged, large-displacement, three-cylinder engine with improved power and torque and quiet operation. These engines are more fuel efficient and feature a common rail, direct-injected, electronic fuel management system. A two-position, extendable drawbar comes standard. Telescopic stabilizers and fixed link ends make hookup easy for three-point-mounted implements. You can never have to many attachment options.

ENVIRONMENTALLY FRIENDLY

These compact tractors are environmentally friendly, meeting or exceeding the latest emissions requirements for cleaner air without the need for added fluids. The automatic system used on the Workmaster 35 and 40 combines internal Exhaust Gas Recirculation (EGR) and a Diesel Oxidation Catalyst (DOC) with a Diesel Particulate Filter (DPF) to achieve stringent Tier 4B emissions levels.

FUEL SAVING POWER

workmaster25-35-40-gallery
The Workmaster 35 and 40 feature turbocharged, large-displacement, three cylinder engines for improved power and torque and quiet operation. These engines are more fuel efficient and feature a common rail, direct-injected, electronic fuel management system.

Specs

Engine
Aspiriation
Turbo
Displacement
114.7 cu in
Emissions Tier (EPA)
Tier 4B
Gross HP
40 hp
No. Of Cylinders
3
Performance
Lift Capacity at 24" behind lift Point
1433 lbs
PTO
540 rpm
PTO HP
32-34 hp
Front linkage lift capacity (24 in. (610 mm) in front of ball ends) (lbs. (kg))
1808 lbs
Dimensions & Weight
Height
87.7 in
Length
121 in
Operating Weight
3067 lbs
Wheel base
67.5 in
Width
66.5 in
Capacities
Fuel Tank
7.4 gal
Transmission
Transmission
Hydrostatic (HST), Gear Drive
Transmission Range
12x12, 3-Range
Make/Model
Model
Workmaster 40
Type
Compact Tractor
Product Dimensions & Weight
Length
121.00 in
Width
66.50 in
Height
87.70 in
Weight
3067.00 lbs
