Product Description

MEET THE SL12 TR ARTICULATED LOADER
For those in need of a little more arm reach, the CASE SL12 TR telescopic boom model has you covered. With a lifting height of 108”, you get over two additional feet of extension, giving you the ability to offload to taller trailers, place mulch or stone with more precision, or use a fork to stack pallets. The small size of this machine lets you wiggle into tight places, and the narrow width is ideal for use clearing snow-covered sidewalks. Plus, the lower operating weight and articulated steering minimizes damage to ground surfaces.
Specs
Additional Specs | |
---|---|
Keyed Ignition | Standard |
Operator Station | ROPS, FOPS |
Engine | |
---|---|
Displacement | 54.8 cu in |
Emissions Tier (EPA) | Tier 4 |
Engine Cooling | Liquid |
Engine Model | Kubota D902 |
Fuel Type | Diesel |
Gross HP | 25 hp |
No. Of Cylinders | 3 |
Performance | |
---|---|
Lift Capacity | 2425 lb |
Travel Speed | 9.3 mph |
Tipping Load | 2205 lb (straight) |
Dump Angle @ Max Height | 40 degrees |
Driveline | 4WD |
Dimensions & Weight | |
---|---|
Height | 81.1 in |
Length | 89.2 in |
Length with Standard Bucket | 115.2 in |
Length without Attachment | 89.2 in |
Operating Weight | 2646 lb |
Reach @ Maximum Height | 85.4 in |
Rollback Angle | 43-50 degrees |
Turning Radius Outside | 87.6 in |
Turning Radius | 38.5 in |
Wheel base | 49.1 in |
Width | 36.2 in |
Capacities | |
---|---|
Hydraulic Tank | 12.7 gal |
Fuel Tank | 12.2 gal |
Hydraulic System | |
---|---|
Aux Hydraulics Pressure | 2200-5100 psi |
Hydraulic System | Gear |
Transmission | |
---|---|
Transmission | Hydrostatic (HST) |
Transmission Range | 2-Speed |
Make/Model | |
---|---|
Model | SL12TR |
Type | Articulated Loader |
Product Dimensions & Weight | |
---|---|
Length | 89.20 in |
Width | 36.20 in |
Height | 81.10 in |
Weight | 2646.00 lbs |
